CAS 155 G 1/4" 0-8 BAR
DIFFERENTIAL PRESSURE CONTROL
CAS 155 G 1/4" 0-8 BAR DIFFERENTIAL PRESSURE CONTROL
Catalog number
204457001
EAN
5702423151646
Manufacturer number
060-313066
Country of origin
PL
HS number
90322000
- Delivery stock products within 1-2 working days
- Free delivery Netherlands > € 200,00 net
- High stock level compressor spare parts
- Only registered THIMAR customers
Product information "CAS 155 G 1/4" 0-8 BAR"
CAS, heavy-duty pressure switch
In the CAS pressure switches series, special attention has been given to meeting demands for a high level of enclosure, low differential, robust, compact construction and resistance to shock and vibration. The CAS series covers most outdoor as well as indoor application requirements. CAS pressure switches are suitable for use in alarm and regulation systems in factories, diesel plant, compressors, power stations and on board ships.
In the CAS pressure switches series, special attention has been given to meeting demands for a high level of enclosure, low differential, robust, compact construction and resistance to shock and vibration. The CAS series covers most outdoor as well as indoor application requirements. CAS pressure switches are suitable for use in alarm and regulation systems in factories, diesel plant, compressors, power stations and on board ships.
| Ambient temperature range [°C] [max]: | 70 °C |
|---|---|
| Ambient temperature range [°C] [min]: | -25 °C |
| Ambient temperature range [°F] [max]: | 158 °F |
| Ambient temperature range [°F] [min]: | -13 °F |
| Approval(s): | ABS BV CCC CE DNV EAC GL LLC CDC EURO-TYSK LR LVD NKK RINA RMRS RoHS RoHS China TYSK |
| Burst pressure [bar]: | 42 bar |
| CE evaluated: | Yes |
| China RoHS compliance: | Out of scope |
| Contact differential [bar]: | 0.1 bar |
| Contact function: | SPDT |
| Contact rating: | AC15=0.1 A, 220 V DC13=12 W, 125 V |
| Contains batteries: | No |
| Diff.press.setting range [MPa] [max]: | 0.25 MPa |
| Diff.press.setting range [MPa] [min]: | 0.02 MPa |
| Diff.press.setting range [bar] [max]: | 2.5 bar |
| Diff.press.setting range [bar] [min]: | 0.2 bar |
| Diff.press.setting range [psi] [max]: | 36.2 psi |
| Diff.press.setting range [psi] [min]: | 2.9 psi |
| EU RoHS compliance: | Out of scope |
| Electrical conn. Male/Female: | Female |
| Electrical conn. comments: | Metal cable gland |
| Electrical connection: | Screwed cable entry |
| Electrical connection size: | Pg 13.5 |
| Electrical connection standard: | DIN 40430 |
| Enclosure rating IP: | IP67 |
| Max. Working Pressure [bar]: | 22 bar |
| Max. Working Pressure [psig]: | 319 psig |
| Max. test pressure [bar] Pe: | 22 bar |
| Max. test pressure [psig]: | 319 psig |
| Operat. range LP side [bar] Pe [max]: | 8 bar |
| Operat. range LP side [bar] Pe [min]: | 0 bar |
| Operat. range LP side [psig]Pe [max]: | 115 psig |
| Operat. range LP side [psig]Pe [min]: | 0 psig |
| Packing format: | Multi pack |
| Pressure Male/Female: | Female |
| Pressure connection size: | 1/4 |
| Pressure connection standard: | ISO 228-1 |
| Pressure connection type: | G |
| Product Group: | Switches and thermostats |
| Product Name Description: | Differential pressure switch |
| Product accessories: | Generic accessories |
| Product description: | Diff. Pressure Switch |
| Quantity per packing format: | 8 pc |
| REACH Candidate List substances: | Lead (CAS no. 7439-92-1) |
| Relay release time [s]: | 0 s |
| Reset function: | Auto |
| SCIP dossier no.: | 84be8326-1b95-4f87-afb0-90ae08b65f06 |
| Serviceable: | No |
